毕业设计说明书基于ARM和QT的多路信号检测系统设计摘要PAGEIII摘要随着嵌入式越来越受到重视,嵌入式系统近年来的发展有目共睹,嵌入式系统的应用越来越广泛。无论是传统的工业监测、机械控制,还是新兴的移动通讯、数字娱乐,嵌入式系统正逐渐走进人们的生活生产的方方面面。在工业检测方面,传统的监控系统主要以单片机为硬件载体进行设计,功能相对单一,可视化及拓展性有限。随着Linux系统的不断升级换代,现在出现了以ARM芯片为载体,以Linux系统为软件平台设计出的新一代监控系统。除了能实现原有单片机的功能外,其可视化更强,具备网络通信功能,是一台具备功能拓展更丰富的微型计算机。本文将以北京博创兴业科技有限公司提供的UP-NetARM2410-S实验仪器为硬件载体,对监测系统的设计进行研究和应用。系统平台使用的是Linux2.4.18的内核,GUI首次以Qt为底层图形模块,用C++和Qt图形用户界面类库开发图形数据一体化监控平台。本文先从硬件平台设计入手,根据要求对硬件设备进行了解,设计了功能模块,在软件部分移植了Linux操作系统平台,构建了开发环境,就数模转换、触摸屏驱动程序进行编程,最后详述在了Qt下,如何使用C++语言设计监控系统图形界面。最后展现了系统运行效果,并提出了改进意见。运行效果表明,设计的监控系统是有效和实时的。关键词:嵌入式系统Linux驱动QtAbstractAbstractWiththeincreasingimportanceofembeddedtechnology,thedevelopmentofembeddedsystemsforalltoseeinrecentyears,embeddedsystemapplicationsincreasinglybroad.Whetherintraditionalindustrialmonitoring,mechanicalcontrol,ortheemergingmobilecommunications,digitalentertainment,embeddedsystemsaregraduallymovedintoallaspectsofproductionandlivesofthepeople.Intheindustrialtesting,thetraditionalembeddedcontrolsystemsprimarilyforthesingle-chipmicrocomputerhardwarevectordesignfunctionrelativelysingle,visualization,andlimitedscalability.WiththeLinuxsystemconstantlyupgradingandupdating,andnowappearedtoARMchipcarrierandLinuxsystemssoftwareplatformdesignedforanewgenerationofmonitoringsystem.Inadditiontoachievingtheoriginalmicrocontrollerfunctions,visualizationsstronger,equippedwiththenetworkcommunicationfunctionisafunctionofdevelopingamoreabundantmicro-computer.Thispaper,basedonUP-NetARM2410-SexperimentinstrumentprovidedbytheBeijingUniversalPioneeringTechnologyCo.,LTD.,designsamonitoringsystemtoconductresearchandapplication.SystemplatformisLinux2.4.18kernel,GUIforthefirsttimeinthebottomQtgraphicsmodule,usingC++andQtgraphicaluserinterfacelibrarymonitorthedevelopmentofgraphicaldataintegrationplatform.Thisarticlefirststartwiththehardwareplatformdesign,requiredtounderstandthehardwaredevicesdesignedmodules,portedinthesoftwarepartoftheLinuxoperatingsystemplatform,bui
