管线表金安矿业年产100万吨矿山充填胶结剂厂一期建设工程31-12-2009子项:∅3.2X14m磨磨房,成品均化散装库,气力输送系统（Y9012-1202,1203,1204-ZS）方向电缆保护管序号管线号仪表位号电压(V)敷设方式备注来自到型号长度(m)直径(mm)长度(m)1TED01TE-D01DCS系统柜TE-D01DJYVPR-4x1.0120205QJ,GG2TED02TE-D02DCS系统柜TE-D02DJYVPR-4x1.0100205QJ,GG3TED05TE-D02DCS系统柜TE-D02DJYVPR-4x1.090205QJ,GG4TUTD01TUT-D01DCS系统柜TUT-D01DJYVPR-2x1.080205QJ,GG5TUTD01-1TUT-D01TUT-D01主电机2XDJYVPR-4x1.010205QJ,GG6TUTD02TUT-D02DCS系统柜TUT-D02DJYVPR-2x1.080205QJ,GG7TUTD02-1TUT-D02TUT-D02主电机6XDJYVPR-4x1.010205QJ,GG8PTD01PT-D01DCS系统柜PT-D01DJYVPR-2x1.090205QJ,GG9PTD02PT-D02DCS系统柜PT-D02DJYVPR-2x1.090205QJ,GG10PDHD01PDH-D01DCS系统柜PDH-D01KVV-0.5KV2x1.5120205QJ,GG11PDHD01-DPDH-D01仪表电源柜PDH-D01AC220VKVV-0.5KV3x1.5120205QJ,GG12LTD01LT-D01DCS系统柜LT-D01DJYVPR-2x1.0110205QJ,GG13LTD01-DLT-D01仪表电源柜LT-D01AC220VKVV-0.5KV3x1.5110205QJ,GG14LHD01LH-D01DCS系统柜LH-D01KVV-0.5KV2x1.5110205QJ,GG15LHD01-DLH-D01仪表电源柜LH-D01AC220VKVV-0.5KV3x1.5110205QJ,GG16TED03TE-D03DCS系统柜TE-D03DJYVPR-4x1.090205QJ,GG17TED04TE-D04DCS系统柜TE-D04DJYVPR-4x1.070205QJ,GG18TED06TE-D02DCS系统柜TE-D02DJYVPR-4x1.090205QJ,GG19TUTD03TUT-D03DCS系统柜TUT-D03DJYVPR-2x1.080205QJ,GG20TUTD03-1TUT-D03TUT-D03主电机2XDJYVPR-4x1.010205QJ,GG21TUTD04TUT-D04DCS系统柜TUT-D04DJYVPR-2x1.080205QJ,GG22TUTD04-1TUT-D04TUT-D04主电机6XDJYVPR-4x1.010205QJ,GG23PTD03PT-D03DCS系统柜PT-D03DJYVPR-2x1.060205QJ,GG24PTD04PT-D04DCS系统柜PT-D04DJYVPR-2x1.060205QJ,GG25PDHD02PDH-D02DCS系统柜PDH-D02KVV-0.5KV2x1.5130205QJ,GG26PDHD02-DPDH-D02仪表电源柜PDH-D02AC220VKVV-0.5KV3x1.5130205QJ,GG27LTD02LT-D02DCS系统柜LT-D02DJYVPR-2x1.0130205QJ,GG28LTD02-DLT-D02仪表电源柜LT-D02AC220VKVV-0.5KV3x1.5130205QJ,GG29LHD02LH-D02DCS系统柜LH-D02KVV-0.5KV2x1.5130205QJ,GG30LHD02-DLH-D02仪表电源柜LH-D02AC220VKVV-0.5KV3x1.5130205QJ,GG31PDHD03PDH-D03DCS系统柜PDH-D03KVV-0.5KV2x1.5100205QJ,GG32PDHD03-DPDH-D03仪表电源柜PDH-D03AC220VKVV-0.5KV3x1.5100205QJ,GG3334PDHE01PDH-E01DCS系统柜PDH-E01KVV-0.5KV2x1.5140205QJ,GG35PDHE01-DPDH-E01仪表电源柜PDH-E01AC220VKVV-0.5KV3x1.5140205QJ,GG36LTE01LT-E01DCS系统柜LT-E01DJYVPR-2x1.0140205QJ,GG37LTE01-DLT-E01仪表电源柜LT-E0
