基于PLC和变频器的T610卧式镗床电气控制系统设计摘要在当代建造规模中,金属切削加工在全体机械制造中盘踞极重的职位,机械制造工作中的百分之四十到六十被其占据。然而镗床更是有着举足轻重的作用。在1770年左右,就诞生了第一台原始的卧式镗床。随着科学技术飞速的突破性发展的步伐,加工各种繁杂大型零件的卧式镗床研发成功于1999年前后。随着加工零件要求的不断增高,镗床也随之不断发展起来,正是由于其市场需求,使得一种通用性好、满足加工零件需求的卧式镗床应运而生。T610型卧式镗床是钻孔领域不可或缺的一员。原因归结于卧式型的镗床不仅仅是拓展工件上的已经存在的或已经加工完成后的孔,卧式型的这种镗床的特色在于它能够铣削、加工外圆和螺纹以及其他。最初的T610卧式镗床出现电气故障的频率总体来说较高的原因是由于继电器控制系统的选备,不仅仅是维修保养费时费力的问题,经济消耗较高。出现这些故障的原因是继电器控制系统的配置选择。在本次的毕业设计中经过甄选,决定使用西门子S7-200PLC,主要处于对经济效益的考虑,以及任务的完成度,在变频器方面综合考虑最终选择MM440.用这两个器件综合改善传统卧式镗床的不足,提升生产质量。关键词:T610卧式镗床,电气控制,PLC,变频器ABSTRACTIncontemporaryconstructionscaleandmetalcuttingprocessinginallmachinerymanufacturingentrenchedexercisedposition,mechanicalmanufacturingworkfortytosixtypercentisoccupyits.However,theboringmachineisaroleplayadecisiverole.Around1770,wasbornthefirstoriginalhorizontalboringmachine.Withthedevelopmentofscienceandtechnologybreakthroughrapidpace,processingallkindsofcomplicatedlargepartsofthehorizontalboringmachinesuccessfullydevelopedin1999.Thecontinuousdevelopmentofboringmachineispreciselyduetotheprocessingofpartsoftheconstantlychanging,withgeneral,millionyearsofcharacteristicsofhorizontalboringmachineeventuallydevelopvariableasaleaderincontemporaryboringmachineisalsoreasonable.Intheprocessingofholes,T610thistypeofhorizontalboringmachineoccupiesaveryimportantposition.Attributedtotypehorizontalboringmachineisnotonlyexpandtheholesonthedevicealreadyexistsorhasbeenmanufacturedafter,thecharacteristicsofHorizontaltypeboringmachineisitcanbemilling,machiningcircleandthreadsandother.TraditionalT610horizontalboringmachineduetotherelativelyhighfrequencyoftherelaycontrolsystemofelectricalaccidents.InadditionRepairandmaintenancedifficultandexpensive,thefaultreasonistheconfigurationselectionofrelaycontrolsystem.Inthegraduationdesign,afterselection,thefinaldecisiontouseSiemensS7-200PLC,Mainlyintheeconomicbenefitsoftheconsideration,andtaskcompletion,ConsideringinthefinalselectionofMM440inverter.Withthesetwodevicesareintegratedtoimprovethetradition
